FOR THE REMOVAL OF IRON, MANGANESE, ARSENIC, ALUMINIUM, HYDROGEN SULFIDE AND OTHER HEAVY METALS FROM WATER SUPPLIES INFUSION TECHNOLOGY:
Power oxidizing agents are chemically infused to the micro porous sub-structure of the matrix material. Infusion Technology increases the catalytic surface and gives IRM the highest oxidation rate and load capacity of any other catalytic media. Infusion Technology allows for very small attrition loss and displays no decaying effect or loss or catalysis for up to 5 -10 years of continuous performance.
IRM protects and pre-treats all other water treatment systems from iron and manganese bio-fouling, effectively longer filter run times, and with the benefit of reduced oxidant demand and because IRM Infusion Technology requires no chemical regeneration,
Iron Removal Media (IRM) Product Specifications
| Infusion Technology | Catalytic layers are infused into the substrate matrix material -not just a coating, like other medias, IRM unique infusion technology lasts longer |
|---|---|
| Power Load Capacity | 18000 grains of oxidised Fe & Mn sq feet of IRM, at LV 10M3/M2/hr, allows for 50% greater filter run times. |
| Oxidation Booster | Catalytic Surface is the stronger oxidising booster that is the most efficient material in the world to remove Mn to undetectable levels. |
| Specific Gravity 2.69 | Effective Size 0.35 - 0.65 mm |
| Bulk Density 1460 kg/m3 | Uniform Coefficient 1.4 to 1.7 |
| Mesh Size 20 - 40 | Water pH range 5.8 -8.6 |
| Optimum pH Performance 7.0 - 8.0 | Maximum Water Temperature 60° C |
| Free Board 40% of bed depth (min) | Regeneration Between - No Regeneration Required |
| Service flow rate 5-20 m3 / m2 /hr | Backwash flow rate Between 25-40 m3 / m2 /hr |
| Attrition Loss per annum less than 2% | Backwash bed expansion Between 15-50 % |
| Expected Life Span | Up to 10 years continuous use depends upon raw water parameter & operating condition. |
